PRO170R3 > Small Block Chevrolet 1957-1985
PRO170R3 - $734.25
- Style:
- Small Block Chevrolet 1957-1985
- Dimensions:
- 5 1/2" deep
Description:This aluminum dry sump oil pan is for the Small Block Chevrolet years 1957-1985 with the two piece rear main seal engines. This oil pan features:
- a kick out pouch that starts at the pan rail and goes to the bottom of the pan
- .100” aluminum
- access holes for mounting
- three -12 o-ring ports that exit the top right side of the pan
- an inspection hole
- a drain plug
- a louvered windage tray
No pan gasket required.
It will clear a mechanical fuel pump.
Use: Dirt circle track (late model)
Starter: Reverse mounted
Dimensions: 5 1/2" deep on right side; 4 1/4" deep on left side
Related Products
| Name | Application | Info | Price |
|---|---|---|---|
| CP15012 | PRO170s, PRO180s | Louvered windage tray | $34.93 |
